Ubiquiti UDM-PRO-MAX UniFi Dream Machine Pro Max - Combined Switch / Security Gateway / Controller / UniFi Protect NVR
$966.00
10G Cloud Gateway with Integrated NVR and Advanced Security
High-performance cloud gateway designed to support large UniFi deployments with powerful routing, security, and video storage capabilities.
Key Features
- Supports 200+ UniFi devices and 2,000+ clients
- Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE
- Full UniFi application suite included for comprehensive device management
- 5 Gbps routing with IDS/IPS for secure, high-throughput connectivity
- Redundant NVR storage with dual 3.5" HDD bays and RAID data protection
- Built-in 128 GB SSD for NVR detection recordings
- UniFi Power Backup ready
- 1.3" touchscreen for at-a-glance status and control
Networking & Interfaces
- LAN
- (8) GbE RJ45 ports
-
(1) 10G SFP+ port
-
WAN
- (1) 2.5 GbE RJ45 port
-
(1) 10G SFP+ port
-
Management Interfaces
- Ethernet
-
Bluetooth
-
IDS/IPS Throughput
- 5 Gbps
- Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
Advanced Performance & Routing
- Redundant WAN with failover and load balancing
- WiFi QoS with UniFi APs
- Application, domain, and country-based QoS
- Application and device type identification
- Additional internet failover with LTE Backup
- Internet quality and outage reporting
Next Generation Security
- Application-aware firewall rules
- Signature-based IPS/IDS threat detection
- Content, country, domain, and ad filtering
- VLAN/subnet-based traffic segmentation
- Full stateful firewall
Advanced Networking & VPN
- License-free SD-WAN
- WireGuard, L2TP, and OpenVPN server
- OpenVPN client
- OpenVPN and IPsec site-to-site VPN
- One-click Teleport and Identity VPN
- Policy-based WAN and VPN routing
- DHCP relay
- Customizable DHCP server
- IGMP proxy
- IPv6 ISP support
Hardware Specifications
| Category | Details |
|---|---|
| Processor | Quad-core ARM Cortex-A57 at 2.0 GHz |
| System Memory | 8 GB DDR4 |
| Onboard Storage | 32 GB eMMC |
| Integrated SSD | 128 GB SSD for NVR detection recordings |
| NVR Storage Bays | (2) 3.5" HDD bays with RAID data protection |
| Touchscreen | 1.3" touchscreen |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Mount Material | SGCC steel |
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Weight | 4.7 kg |
Power & Electrical
| Category | Details |
|---|---|
| Power Method | (1) Universal AC input, 100–240V AC, 2A Max., 50/60 Hz |
| (1) USP-RPS DC input, 11.5V DC, 8.7A | |
| Power Supply | AC/DC, internal, 100W |
| Supported Voltage Range | 100–240V AC |
| Max Power Consumption | 100W |
Summary
This 10G cloud gateway delivers high-capacity UniFi management, 5 Gbps IDS/IPS routing, robust SD-WAN and VPN options, and integrated NVR functionality with redundant storage—ideal for demanding, security-focused networks.
