Ubiquiti UDB-PRO Plug and Play Wireless Device Bridge Pro
$332.00
5 GHz Long-Range Wireless Bridge with PoE Output
A high-performance 5 GHz wireless bridge designed for long-distance links up to 5+ km and seamless uplinks to UniFi WiFi networks.
Note: This device cannot be set up standalone. It must be managed by a UniFi Console, Official UniFi Hosting, or a Self-Hosted UniFi Network Server.
A PoE adapter is included. A PoE+ input is required to enable PoE passthrough.
Key Features
- 5 GHz wireless bridge for long-distance connectivity (5+ km)
- Seamless uplink to UniFi WiFi
- PoE output with PoE+ input required for passthrough
- Weatherproof IPX6 enclosure
- Wall or pole mounting options
- WPA2 AES wireless security (always on)
- Managed via UniFi Console, Official UniFi Hosting, or Self-Hosted UniFi Network Server
Technical Specifications
| Category | Specification |
|---|---|
| WiFi Standard | WiFi 5 (802.11ac) |
| Spatial Streams | 2 |
| Coverage Area | 5 km (3.1 mi) |
| Max. Data Rate | 867 Mbps (BW80) |
| MIMO | 2 x 2 |
| Antenna Gain | 19 dBi |
| Max. TX Power | 25 dBm |
| Max. Conducted TX Power | 25 dBm (Combined) |
| Supported Data Rates | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n: 6.5 Mbps to 300 Mbps (MCS0–MCS15, HT 20/40) | |
| 802.11ac (WiFi 5): 6.5 Mbps to 866.7 Mbps (MCS0–MCS9 NSS1/2, VHT 20/40/80) | |
| Wireless Security | WPA2 AES (Always On) |
| Channel Bandwidth | 20/40/80 MHz |
Power & Networking
| Category | Specification |
|---|---|
| Power Method | PoE |
| PoE+ Requirement | PoE+ required for PoE output |
| Max. Power Consumption | 9 W |
| Supported Voltage Range | 42.5–57V DC |
| Networking Interface | (2) GbE RJ45 ports |
| PoE Ports | (1) PoE in (when PoE output not used) |
| PoE Adapter | Included |
Hardware & Design
| Category | Specification |
|---|---|
| Dimensions | Ø189.5 x 64.3 mm (Ø7.4 x 2.5") |
| Weight | Device: 431 g (0.95 lb) |
| With mount: 515 g (1.1 lb) | |
| Enclosure Material | UV-resistant polycarbonate |
| Mount Material | UV-stabilized polycarbonate, stainless steel |
| Mounting Locations | Wall / Pole |
| Pole Mount Diameter | 0.8–2.1" (20–53.1 mm) |
| Antennas | Internal |
| Weatherproofing | IPX6 |
| Wind Loading | 69 N at 200 km/h (15.5 lbf at 125 mph) |
| Button | (1) Factory-reset |
| System LEDs | Power, Ethernet, (4) signal strength |
Management & Certifications
| Category | Specification |
|---|---|
| Management | UniFi Console, Official UniFi Hosting, or Self-Hosted UniFi Network Server |
| Certifications | CE, FCC, IC |
