Intel Core (BX80768265) Ultra 7 Processor 265 Processor 20 Core, 20 Threads, 2.4GHz up to 5.3GHz Turbo, LGA 1851 Socket, 66MB Cache, 65W, Maximum Turbo Power182W

Intel Core Ultra 7 Processor 265

The Intel Core Ultra 7 Processor 265 delivers a powerful combination of high-performance cores, efficient cores, integrated graphics, and dedicated AI acceleration for demanding modern workloads.

CPU Specifications

• Total Cores: 20
• Performance-cores: 8
• Efficient-cores: 12
• Low Power Efficient-cores: 0
• Total Threads: 20
• Max Turbo Frequency: 5.3 GHz
• Intel Turbo Boost Max Technology 3.0 Frequency: 5.3 GHz
• Performance-core Max Turbo Frequency: 5.2 GHz
• Efficient-core Max Turbo Frequency: 4.6 GHz
• Performance-core Base Frequency: 2.4 GHz
• Efficient-core Base Frequency: 1.8 GHz
• Cache: 30 MB Intel Smart Cache
• Total L2 Cache: 36 MB
• Processor Base Power: 65 W
• Maximum Turbo Power: 182 W
• Intel Deep Learning Boost (Intel DL Boost) on CPU: Yes
• AI Software Frameworks Supported by CPU: OpenVINO, WindowsML, DirectML, ONNX RT, WebNN
• CPU Lithography: TSMC N3B

Memory Specifications

• Max Memory Size (dependent on memory type): 256 GB
• Memory Types: Up to DDR5 6400 MT/s
• Max Number of Memory Channels: 2
• ECC Memory Supported: Yes

GPU Specifications

• GPU Name: Intel Graphics
• Graphics Base Frequency: 300 MHz
• Graphics Max Dynamic Frequency: 1.95 GHz
• GPU Peak TOPS (Int8): 8
• Graphics Output: eDP 1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
• Xe-cores: 4

Maximum Resolutions‡

• HDMI (HDMI 2.1 TMDS): 4096 x 2304 @ 60Hz
• HDMI (HDMI 2.1 FRL): 7680 x 4320 @ 60Hz
• DisplayPort (DP): 7680 x 4320 @ 60Hz
• eDP – Integrated Flat Panel: 3840 x 2400 @ 120Hz

Graphics & Media Support

• DirectX Support: 12
• OpenGL Support: 4.5
• OpenCL Support: 3
• H.264 Hardware Encode/Decode: Yes
• H.265 (HEVC) Hardware Encode/Decode: Yes
• AV1 Encode/Decode: Yes
• Intel Quick Sync Video: Yes
• Number of Displays Supported‡: 4
• Intel Deep Learning Boost (Intel DL Boost) on GPU: Yes
• AI Software Frameworks Supported by GPU: OpenVINO, WindowsML, DirectML, ONNX RT, WebGPU

NPU Specifications

• NPU Name‡: Intel AI Boost
• NPU Peak TOPS (Int8): 13
• Sparsity Support: Yes
• Windows Studio Effects Support: Yes
• AI Software Frameworks Supported by NPU: OpenVINO, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

• Direct Media Interface (DMI) Revision: 4
• Max Number of DMI Lanes: 8
• Intel Thunderbolt 4: Yes
• Scalability: 1S Only
• PCI Express Revision: 5.0 and 4.0
• PCI Express Configurations‡: Up to 1x16 + 2x4, 2x8 + 2x4, 1x8 + 4x4
• Max Number of PCI Express Lanes: 24

Package Specifications

• Sockets Supported: FCLGA1851
• Thermal Solution Specification: PCG 2022C
• Max Operating Temperature: 105 °C
• Package Size: 45 mm x 37.5 mm
